659 Pleating machine.
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by an alternative energy company in Burnaby BC. The designed function of the machine was to "pick and place" graphite cells and overlay a membrane material. Being a custom prototype machine, The configuration of the machine components, the desired sequencing , as well as user interface was updated frequently. By keeping the code as modular as possible I was able to efficiently update the logic to suit the evolution of the machine. Programming the motion controller on this build was also a great experience, It was a very low level system with regards to interfacing with the logic. Reading and writing of data registers and parameters all required manually coded functions.
My involvement included design and coding of the software for the user interface, motion, and logical systems. Selection, configuration and installation of electrical and electronic components. Design and wiring of the control cabinet. Developing schematic.
- Omron/Sysmac :: PLC/HMI/Motion/Safety

476U Fuel Cell Leak Testing Unit
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by an alternative energy company in Burnaby BC. The designed function of this machine was to compress stacks of cells and test for integrity by applying pressurized gas to simulate hydrogen passing through the cells during use. This machines code was a mod kit on an old press. The control system, drive and motor were updated to Beckhoff.
My involvement included design and coding of the software for the user interface, motion, logical, and safety systems.
- Beckhoff :: PLC/HMI/Motion

653 Fuel Cell Leak Testing Units
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by an alternative energy company in Burnaby BC. The designed function of this machine was to compress stacks of cells and test for integrity by applying pressurized gas to simulate hydrogen passing through the cells during use. This machines code was similar to 672A. The extension of the drive was mechanically adjustable which required some new features and changes to the code. I programmed it using Visual Studio IDE and some API's from Beckhoff Engineering.
My involvement included design and coding of the software for the user interface, motion, logical, and safety systems.
- Beckhoff :: PLC/HMI/Motion

662 Fuel Cell Leak Testing Unit
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by an alternative energy company in Burnaby BC. It was then extensively tested and exported to a customer in China. The designed function of the machine was to compress stacks of cells and test for integrity by applying pressurized gas to simulate hydrogen passing through the cells during use. Being a custom prototype machine, The configuration of the machine components, the desired sequencing , as well as user interface was updated frequently. By using some structured text functions I was able to easily change the compression algorithms to suit changes in design and tune for efficiency during commissioning.
My involvement included design and coding of the software for the user interface, motion, logical, and safety systems. Selection, configuration and installation of electrical and electronic components.
- Omron/Sysmac :: PLC/HMI/Motion/Safety
- Keyence :: Safety

672/672A Fuel Cell Leak Testing Units
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by an alternative energy company in Burnaby BC. The designed function of this machine was to compress stacks of cells and test for integrity by applying pressurized gas to simulate hydrogen passing through the cells during use. This machines code was similar to 662 but had entirely different hardware and software specifications. It utilized Windows 7 Embedded with an Intel Atom Processor for all controlled systems. I programmed it using Visual Studio IDE and some API's from Beckhoff Engineering.
My involvement included design and coding of the software for the user interface, motion, logical, and safety systems.
- Beckhoff :: PLC/HMI/Motion

656 Lithium Cell Conditioning Cabinet
Commonwealth Automation Technologies, Inc
This custom build machine was ordered by a customer in the USA. The designed function of the machine was to test and verify lithium cell battery packs to be installed in pacemakers. Tuning the temperature controller was interesting. The controller would adjust its output by differing excitation frequency of solid state relays. The machine was initially designed with excessive voltage and I had to install step-down transformers to limit the voltage to a suitable range for tuning. After the voltage was decreased, I was able to tune and commission the unit using some integrated PID algorithms in the controller.
My involvement included design and coding of the software for the control system. Configuration and installation of electrical and electronic components.
- Watlow
